YX-60A
ITZ
| Quantity: | |
|---|---|
Motor Voltage: AC 380V 50Hz | Total Power: 6670 W |
Cutting Power: 2×3000 W | Feed Power: 550W |
Cutting speed: 0.7–1.5 m/min (adjustable) | Steel plate weld gap angle: 0°–78° (adjustable) |
Single groove width: 0–20 mm (refer to the spindle feed parameter table in this manual for details) | Bevel thickness: 4–60 mm |
Slope width: 0–80 mm (see the Main Spindle Feed Parameters Table in this manual for details) | Cutting disk blades: 6 pieces |
Minimum clamping disc diameter: ≥800 mm | Net weight of machine: 310 kg |
✅ Adaptive Automatic Curve Tracking Automatically follows the contour of circular and arc steel plates for uniform full-length beveling, greatly reducing manual positioning work.
✅ Precision Cold Milling Finish Burr-free, distortion-free bevel edges, eliminating secondary grinding and directly meeting high-grade welding & NDT standards.
✅ Wide Material & Profile Adaptability Compatible with carbon steel, stainless steel, alloy steel, dished heads and curved structural plates; supports adjustable bevel angles and various bevel shapes.
✅ High-efficiency Automatic Operation Continuous automatic processing, stable operation for mass curved plate production, shortening overall fabrication cycles.
✅ Heavy Industry Application Ideal for pressure vessels, boilers, wind power towers, chemical equipment and large curved component manufacturing.
